SPX3819S-L/TR - MaxLinear, Inc.

Description: LDO Voltage Regulators 500mA LOW NOISE LDO

Download SPX3819S-L/TR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SPX3819S-L/TR - MaxLinear, Inc. PCB footprint - Small Outline Packages - Small Outline Packages - NSOIC8
click to zoom
3D Models
SPX3819S-L/TR - MaxLinear, Inc.  - 3D model - Small Outline Packages - NSOIC8
click to zoom

SPX3819S-L/TR Details

  • Manufacturer Part Number:

    SPX3819S-L/TR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT, MS-012AA, SOIC-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    MaxLinear Inc

  • YTEOL:

    6

  • Dropout Voltage1-Max:

    0.7 V

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    4.9 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Packing Method:

    TR

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Regulator Type:

    ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR

  • Seated Height-Max:

    1.75 mm

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

SPX3819S-L/TR Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and a thermal pad connected to a heat sink is recommended. Ensure a minimum of 1mm clearance around the device for airflow and heat dissipation.
  • Use a pi-network or a T-network topology for input impedance matching. The optimal component values can be determined using simulation tools like ADS or Genesys.
  • Power up the device in the following sequence: VCC, VDD, and then enable the input signal. Power down in the reverse sequence. Ensure a minimum of 10ms delay between power-up and signal application.
  • Use a logic analyzer or an oscilloscope to monitor the device's output and input signals. Check for proper power supply, input signal integrity, and thermal management. Consult the datasheet and application notes for specific troubleshooting guidelines.
  • Handle the device with an ESD wrist strap or mat. Ensure the device is stored in an anti-static bag or tube. Avoid touching the device's pins or exposed die. Follow standard ESD handling procedures.
