SQJ942EP-T1_GE3 - Vishay

Description: Trans MOSFET N-CH 40V 15A/45A Automotive 5-Pin(4+Tab) PowerPAK SO T/R

Download SQJ942EP-T1_GE3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
SQJ942EP-T1_GE3 - Vishay PCB footprint - Other - Other - PowerPAK® SO-8L Assymetric
click to zoom

SQJ942EP-T1_GE3 Details

  • Manufacturer Part Number:

    SQJ942EP-T1_GE3

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SMALL OUTLINE, R-PSSO-G4

  • Reach Compliance Code:

    Unknown

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    Vishay Intertechnologies

  • YTEOL:

    5

  • Avalanche Energy Rating (Eas):

    18.5 mJ

  • Case Connection:

    DRAIN

  • Configuration:

    SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    40 V

  • Drain Current-Max (ID):

    15 A

  • Drain-source On Resistance-Max:

    0.022 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • JESD-30 Code:

    R-PSSO-G4

  • Number of Elements:

    2

  • Number of Terminals:

    4

  • Operating Mode:

    ENHANCEMENT MODE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Polarity/Channel Type:

    N-CHANNEL

  • Pulsed Drain Current-Max (IDM):

    60 A

  • Surface Mount:

    YES

  • Terminal Form:

    GULL WING

  • Terminal Position:

    SINGLE

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Transistor Element Material:

    SILICON

SQJ942EP-T1_GE3 Frequently Asked Questions (FAQs)

  • The recommended storage temperature range for SQJ942EP-T1-GE3 is -40°C to 125°C, as per Vishay's general guidelines for storage and handling of semiconductor devices.
  • While the SQJ942EP-T1-GE3 is designed to operate in a wide range of temperatures, it's not recommended for use in high-humidity environments (> 80% RH) without proper protection, such as conformal coating or hermetic sealing, to prevent moisture-related failures.
  • The maximum allowable voltage derating for the SQJ942EP-T1-GE3 is typically 10% to 15% below the maximum rated voltage, depending on the specific application and operating conditions. However, it's recommended to consult with Vishay's application engineers or a qualified design expert for specific guidance.
  • Yes, the SQJ942EP-T1-GE3 is compatible with lead-free soldering processes, as it meets the requirements of the RoHS (Restriction of Hazardous Substances) directive and is designed to withstand the higher temperatures associated with lead-free soldering.
  • The recommended PCB layout and land pattern for the SQJ942EP-T1-GE3 can be found in Vishay's application notes and design guides, which provide detailed information on pad layout, thermal management, and PCB design considerations.
