SQM120N04-1m7L_GE3 - Vishay

SQM120N04-1m7L_GE3 Details

• Manufacturer Part Number:

  SQM120N04-1M7L_GE3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMALL OUTLINE, R-PSSO-G2

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Factory Lead Time:

  18 Weeks

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  5.6

• Avalanche Energy Rating (Eas):

  423 mJ

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  40 V

• Drain Current-Max (ID):

  120 A

• Drain-source On Resistance-Max:

  0.0017 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  908 pF

• JEDEC-95 Code:

  TO-263AB

• JESD-30 Code:

  R-PSSO-G2

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  480 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE

• Transistor Element Material:

  SILICON

• Turn-off Time-Max (toff):

  128 ns

• Turn-on Time-Max (ton):

  38 ns
