The recommended land pattern for SQP25AJB-10R is a rectangular pad with a size of 1.3mm x 0.8mm, with a non-solder mask defined (NSMD) pad shape. The pad should be centered on the component and have a solder mask clearance of 0.1mm.
Yes, SQP25AJB-10R is rated for operation up to 150°C, making it suitable for high-temperature applications. However, the component's performance and reliability may degrade at temperatures above 125°C, so careful consideration should be given to the specific application requirements.
Yes, SQP25AJB-10R is compatible with lead-free soldering processes, including SAC305 and Sn96.5Ag3Cu0.5. The component's termination finish is pure tin (Sn) and is compatible with most lead-free soldering processes.
The MSL of SQP25AJB-10R is 1, which means it can withstand a maximum of 30 days of exposure to ambient humidity and temperature conditions before soldering. Proper storage and handling procedures should be followed to prevent moisture absorption.
Yes, SQP25AJB-10R is suitable for high-frequency applications up to 1 GHz. The component's self-resonant frequency is typically above 1 GHz, making it suitable for use in high-frequency circuits. However, the component's performance may degrade at frequencies above 500 MHz, so careful consideration should be given to the specific application requirements.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SQP25AJB-10R Overview
Use the download button to access the SQP25AJB-10R schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SQP25,
or try a keyword search, such as Wire Wound Resistors
