SR6C4024 - TE Connectivity

SR6C4024 Details

• Manufacturer Part Number:

  SR6C4024

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• Body Breadth:

  16.5 mm

• Body Height:

  16.5 mm

• Body Length or Diameter:

  55 mm

• Coil Current(DC)-Max:

  0.05 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  1200 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  480 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  8A@400VAC

• Contact Current(AC)-Max:

  8 A

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  400 V

• Electrical Life:

  6050 Cycle(s)

• End Contact Material:

  Silver Tin Oxide

• Input Switching Control Type:

  Random

• Mounting Feature:

  THROUGH HOLE-STRAIGHT MOUNT

• Number of Terminals:

  14

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Packing Method:

  BULK

• Physical Dimension:

  55mm X 16.5mm X 16.5mm

• Reference Standard:

  TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  6PST

• Relay Type:

  SAFETY RELAY

• Sealing:

  RT3

• Surface Mount:

  NO

• Terminal Length:

  0.0032994665989331978 inch

• Termination Type:

  SOLDER
