SRP7050AA-2R2M - Bourns

SRP7050AA-2R2M Details

• Manufacturer Part Number:

  SRP7050AA-2R2M

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Bourns Inc

• YTEOL:

  7

• Case/Size Code:

  2926

• Construction:

  Rectangular

• Core Material:

  METAL ALLOY POWDER

• DC Resistance:

  0.0115 Ω

• Inductance-Nom (L):

  2.2 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  155 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  4.8 mm

• Package Length:

  7.3 mm

• Package Style:

  SMT

• Package Width:

  6.6 mm

• Packing Method:

  TR, EMBOSSED, 13 INCH

• Rated Current-Max:

  14 A

• Reference Standard:

  AEC-Q200

• Self Resonance Frequency:

  24 MHz

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  YES

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  WRAPAROUND

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
