SSA-LXB525ID - Lumex

SSA-LXB525ID Details

• Manufacturer Part Number:

  SSA-LXB525ID

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• HTS Code:

  8541.40.20.00

• Manufacturer:

  ITW Lumex

• YTEOL:

  6

• Color:

  HIGH INTENSITY RED

• Color@Wavelength:

  Red

• Configuration:

  SEPARATE, 5 ELEMENTS WITH BUILT-IN RESISTOR

• Forward Current-Max:

  0.025 A

• Lens Type:

  DIFFUSED RED

• Luminous Intensity-Nom:

  10.0 mcd

• Mounting Feature:

  RADIAL MOUNT

• Number of Functions:

  5

• Number of LEDs in Array:

  15

• Number of Terminals:

  10

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -50 °C

• Optoelectronic Device Type:

  SINGLE COLOR LED ARRAY

• Overall Height:

  8.4 mm

• Packing Method:

  BULK

• Peak Wavelength:

  635 nm

• Shape:

  RECTANGULAR

• Size:

  5.3 mm

• Surface Mount:

  NO

• Terminal Pitch:

  2.54 mm

• Viewing Angle:

  110 deg
