SSM6K504NU,LF - Toshiba

Description: N-Channel 30 V 9A (Ta) 1.25W (Ta) Surface Mount 6-UDFNB (2x2)

Download SSM6K504NU,LF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SSM6K504NU,LF - Toshiba - PCB symbol
click to zoom
PCB Footprints
SSM6K504NU,LF - Toshiba PCB footprint - Other - Other - 2-2AA1A
click to zoom
3D Models
SSM6K504NU,LF - Toshiba - 3D model - Other - 2-2AA1A
click to zoom

SSM6K504NU,LF Details

  • Manufacturer Part Number:

    SSM6K504NU,LF

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    UDFN6B, 6 PIN

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    5

  • Case Connection:

    DRAIN

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    30 V

  • Drain Current-Max (ID):

    9 A

  • Drain-source On Resistance-Max:

    0.026 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    42 pF

  • JESD-30 Code:

    S-PDSO-N6

  • Number of Elements:

    1

  • Number of Terminals:

    6

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    150 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    N-CHANNEL

  • Power Dissipation-Max (Abs):

    1.25 W

  • Pulsed Drain Current-Max (IDM):

    18 A

  • Surface Mount:

    YES

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

SSM6K504NU,LF Frequently Asked Questions (FAQs)

  • A thermal pad is recommended under the package to improve heat dissipation. A minimum of 2oz copper thickness and a thermal relief pattern are also recommended.
  • Ensure that the device is operated within the recommended temperature range (TJ = -40°C to 150°C). Use a heat sink if necessary, and ensure good thermal contact between the device and the heat sink.
  • Handle the device by the body, not the leads. Avoid bending or twisting the leads. Store the device in a dry, cool place, away from direct sunlight and moisture.
  • Yes, the SSM6K504NU,LF is a high-reliability device suitable for use in automotive, industrial, and other high-reliability applications. However, additional testing and qualification may be required.
  • Check the device's pinout and connections, ensure proper power supply and decoupling, and verify that the device is operated within the recommended specifications. Consult the datasheet and application notes for troubleshooting guidelines.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SSM6K504NU,LF Overview

Use the download button to access the SSM6K504NU,LF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SSM6K, or try a keyword search, such as Power Field-Effect Transistors
