SSM6P36FE - Toshiba

SSM6P36FE Details

• Manufacturer Part Number:

  SSM6P36FE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ES6, 2-2N1D, 6 PIN

• Pin Count:

  6

• ECCN Code:

  EAR99

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  6.5

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE AND RESISTOR

• DS Breakdown Voltage-Min:

  20 V

• Drain Current-Max (ID):

  0.33 A

• Drain-source On Resistance-Max:

  1.31 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-PDSO-F6

• Number of Elements:

  2

• Number of Terminals:

  6

• Operating Mode:

  ENHANCEMENT MODE

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  P-CHANNEL

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
