SSM6P49NU,LF - Toshiba

Description: Mosfet Array 20V, 4A, 1W, Surface Mount 6-UDFN (2x2), -55°C to +150°C 45mOhm @ 3.5A, 10V, 480pF @ 10V, 480pF @ 10V, 6.74nC @ 4.5V

Download SSM6P49NU,LF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SSM6P49NU,LF - Toshiba - PCB symbol
click to zoom
PCB Footprints
SSM6P49NU,LF - Toshiba PCB footprint - Other - Other - 2-2Y1A_2026
click to zoom
3D Models
SSM6P49NU,LF - Toshiba - 3D model - Other - 2-2Y1A_2026
click to zoom

SSM6P49NU,LF Details

  • Manufacturer Part Number:

    SSM6P49NU,LF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOT-1118, UDFN6, 6 PIN

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • Case Connection:

    DRAIN

  • Configuration:

    SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    20 V

  • Drain Current-Max (ID):

    4 A

  • Drain-source On Resistance-Max:

    0.045 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    76 pF

  • JESD-30 Code:

    S-PDSO-N6

  • Number of Elements:

    2

  • Number of Terminals:

    6

  • Operating Mode:

    ENHANCEMENT MODE

  • Operating Temperature-Max:

    150 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    P-CHANNEL

  • Power Dissipation-Max (Abs):

    1 W

  • Pulsed Drain Current-Max (IDM):

    16 A

  • Surface Mount:

    YES

  • Terminal Form:

    NO LEAD

  • Terminal Position:

    DUAL

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON

SSM6P49NU,LF Frequently Asked Questions (FAQs)

  • A thermal pad on the bottom of the package should be connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended.
  • The device requires a stable input voltage and a proper biasing circuit to ensure optimal performance. A voltage regulator and a bias resistor network can be used to achieve this.
  • Handle the device in an ESD-controlled environment, wear an ESD strap, and use ESD-safe tools and materials to prevent damage. Avoid touching the device's pins or exposed die.
  • Yes, the SSM6P49NU,LF is a high-reliability device that meets the requirements of the automotive and aerospace industries. However, additional testing and qualification may be required for specific applications.
  • Use a systematic approach to troubleshoot the issue, checking the power supply, biasing, and PCB layout. Consult the datasheet and application notes, and contact Toshiba's technical support if necessary.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SSM6P49NU,LF Overview

Use the download button to access the SSM6P49NU,LF schematic symbol, PCB footprint, and 3D model.
