SSTUAF32869AHLFT - Renesas Electronics

SSTUAF32869AHLFT Details

• Manufacturer Part Number:

  SSTUAF32869AHLFT

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  CABGA

• Package Description:

  FPBGA-150

• Pin Count:

  150

• Manufacturer Package Code:

  BKG150

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Family:

  32869

• JESD-30 Code:

  R-PBGA-B150

• JESD-609 Code:

  e1

• Length:

  13 mm

• Logic IC Type:

  D FLIP-FLOP

• Max Frequency@Nom-Sup:

  410000000 Hz

• Max I(ol):

  0.012 A

• Moisture Sensitivity Level:

  3

• Number of Bits:

  14

• Number of Functions:

  1

• Number of Terminals:

  150

• Operating Temperature-Max:

  70 °C

• Output Characteristics:

  OPEN-DRAIN

• Output Polarity:

  TRUE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFBGA

• Package Equivalence Code:

  BGA150,11X19,25

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, THIN PROFILE, FINE PITCH

• Packing Method:

  TR, 13 INCH

• Peak Reflow Temperature (Cel):

  260

• Power Supply Current-Max (ICC):

  100 mA

• Prop. Delay@Nom-Sup:

  2 ns

• Propagation Delay (tpd):

  2 ns

• Seated Height-Max:

  1.2 mm

• Supply Voltage-Max (Vsup):

  1.9 V

• Supply Voltage-Min (Vsup):

  1.7 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Terminal Finish:

  TIN SILVER COPPER

• Terminal Form:

  BALL

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  BOTTOM

• Trigger Type:

  POSITIVE EDGE

• Width:

  8 mm
