ST16C550CJ44 - EXAR

ST16C550CJ44 Details

• Manufacturer Part Number:

  ST16C550CJ44

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, LCC-44

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Exar Corporation

• YTEOL:

  0

• Additional Feature:

  ALSO OPERATES AT 2.97 V MINIMUM SUPPLY

• Address Bus Width:

  3

• Boundary Scan:

  NO

• Clock Frequency-Max:

  24 MHz

• Communication Protocol:

  ASYNC, BIT

• Data Encoding/Decoding Method:

  NRZ

• Data Transfer Rate-Max:

  0.1875 MBps

• External Data Bus Width:

  8

• JESD-30 Code:

  S-PQCC-J44

• JESD-609 Code:

  e0

• Length:

  16.585 mm

• Low Power Mode:

  NO

• Number of DMA Channels:

  1

• Number of I/O Lines:

  2

• Number of Serial I/Os:

  1

• Number of Terminals:

  44

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCJ

• Package Equivalence Code:

  LDCC44,.7SQ

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Qualification Status:

  Not Qualified

• RAM (words):

  0

• Seated Height-Max:

  4.57 mm

• Supply Current-Max:

  3 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  J BEND

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  QUAD

• Width:

  16.585 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
