ST25DV02K-W2R8S3 - STMicroelectronics

Description: Dynamic NFC/RFID tag IC with up to two PWM outputs and 2-Kbit EEPROM

Download ST25DV02K-W2R8S3 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ST25DV02K-W2R8S3 - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
ST25DV02K-W2R8S3 - STMicroelectronics PCB footprint - Small Outline Packages - Small Outline Packages - ST25DV02K-W2R8S3
click to zoom
3D Models
ST25DV02K-W2R8S3 - STMicroelectronics - 3D model - Small Outline Packages - ST25DV02K-W2R8S3
click to zoom

ST25DV02K-W2R8S3 Details

  • Manufacturer Part Number:

    ST25DV02K-W2R8S3

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    13 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    9

  • Consumer IC Type:

    CONSUMER CIRCUIT

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

ST25DV02K-W2R8S3 Frequently Asked Questions (FAQs)

  • The maximum operating frequency of the ST25DV02K-W2R8S3 is 13.56 MHz, as it is an NFC tag IC designed for HF RFID applications.
  • Yes, the ST25DV02K-W2R8S3 is a read/write NFC tag IC, allowing for both reading and writing of data to the tag.
  • The minimum operating temperature range of the ST25DV02K-W2R8S3 is -40°C, and the maximum operating temperature range is 85°C.
  • Yes, the ST25DV02K-W2R8S3 is compliant with ISO/IEC 14443A, ISO/IEC 18092, and NFC Forum Type 2 Tag specifications.
  • The typical current consumption of the ST25DV02K-W2R8S3 is around 10 mA, depending on the operating mode and frequency.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ST25DV02K-W2R8S3 Overview

Use the download button to access the ST25DV02K-W2R8S3 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ST25D, or try a keyword search, such as Other Consumer ICs
