STGSB200M65DF2AG - STMicroelectronics

STGSB200M65DF2AG Details

• Manufacturer Part Number:

  STGSB200M65DF2AG

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Case Connection:

  ISOLATED

• Collector Current-Max (IC):

  216 A

• Collector-Emitter Voltage-Max:

  650 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Gate-Emitter Thr Voltage-Max:

  7 V

• Gate-Emitter Voltage-Max:

  20 V

• JESD-30 Code:

  R-PDSO-G9

• Number of Elements:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  714 W

• Reference Standard:

  AEC-Q101; UL RECOGNIZED

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  POWER CONTROL

• Transistor Element Material:

  SILICON

• Turn-off Time-Nom (toff):

  412.6 ns

• Turn-on Time-Nom (ton):

  193.6 ns

• VCEsat-Max:

  2.05 V
