The recommended torque for the screws on the STMM-120-02-F-D-SM connector is 0.5-1.5 in-lbs (0.056-0.169 Nm) according to Samtec's application notes.
Yes, the STMM-120-02-F-D-SM connector is designed to withstand high-vibration environments. Samtec recommends following their guidelines for vibration testing and ensuring proper screw torque to ensure reliable performance.
The maximum operating temperature for the STMM-120-02-F-D-SM connector is 125°C (257°F) according to the datasheet. However, it's recommended to derate the connector's performance at temperatures above 100°C (212°F).
The STMM-120-02-F-D-SM connector has a moisture sensitivity level (MSL) rating of 1, which means it can withstand normal humidity levels. However, it's not designed for immersion in water or exposure to high-pressure water jets. For humid or wet environments, consider using a connector with a higher MSL rating or applying conformal coating.
The recommended mating cycle for the STMM-120-02-F-D-SM connector is 500-1000 cycles according to Samtec's application notes. However, this may vary depending on the specific application and environmental conditions.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
STMM-120-02-F-D-SM Overview
Use the download button to access the STMM-120-02-F-D-SM schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like STMM-,
or try a keyword search, such as Headers and Edge Type Connectors
