STPA003HSD-48X - STMicroelectronics

STPA003HSD-48X Details

• Manufacturer Part Number:

  STPA003HSD-48X

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  FLEXIWATT-27

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  52 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  5

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  CLASS AB AUDIO AMPLIFIER

• Harmonic Distortion:

  0.01%

• JESD-30 Code:

  R-XZFM-T27

• JESD-609 Code:

  e3

• Length:

  29.23 mm

• Number of Channels:

  4

• Number of Functions:

  1

• Number of Terminals:

  27

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Power-Nom:

  55 W

• Package Body Material:

  UNSPECIFIED

• Package Code:

  ZFM

• Package Equivalence Code:

  ZIP27,.16,.16,40

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Seated Height-Max:

  19.37 mm

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  6 V

• Surface Mount:

  NO

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1 mm

• Terminal Position:

  ZIG-ZAG

• Width:

  4.5 mm
