STSPIN32F0602 - STMicroelectronics

Description: Motor / Motion / Ignition Controllers & Drivers 600V three-phase controller with MCU

Download STSPIN32F0602 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
STSPIN32F0602 - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
STSPIN32F0602 - STMicroelectronics PCB footprint - Quad Flat Packages - Quad Flat Packages - LQF64-
click to zoom
3D Models
STSPIN32F0602 - STMicroelectronics - 3D model - Quad Flat Packages - LQF64-
click to zoom

STSPIN32F0602 Details

  • Manufacturer Part Number:

    STSPIN32F0602

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    3A991.A.2

  • HTS Code:

    8542.31.00.30

  • Factory Lead Time:

    20 Weeks

  • Date Of Intro:

    2019-09-06

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    9

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • uPs/uCs/Peripheral ICs Type:

    Motion Control Microcontroller

STSPIN32F0602 Frequently Asked Questions (FAQs)

  • The maximum operating frequency of the STSPIN32F0602 is 100 kHz, but it can be overclocked up to 200 kHz with reduced performance and increased power consumption.
  • The STSPIN32F0602 can be configured for 3-phase motor control by using the SPI interface to set the motor control registers. The device supports various motor control modes, including sinusoidal, trapezoidal, and FOC (Field-Oriented Control). Refer to the application note AN5155 for detailed configuration and programming guidelines.
  • The maximum current rating of the STSPIN32F0602 is 2A per phase, but it can be increased up to 4A per phase with proper heat sinking and thermal management.
  • The STSPIN32F0602 has built-in overcurrent and overvoltage protection features. The device can be configured to detect overcurrent conditions and shut down the output stage to prevent damage. Additionally, the device has an overvoltage protection feature that can detect voltage surges and spikes and shut down the output stage to prevent damage.
  • Yes, the STSPIN32F0602 can be used for brushless DC motor control. The device supports various motor control modes, including trapezoidal and sinusoidal commutation, which are suitable for brushless DC motor control.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

STSPIN32F0602 Overview

Use the download button to access the STSPIN32F0602 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like STSPI, or try a keyword search, such as Other uPs/uCs/Peripheral ICs
