STTH30RQ06L2-TR - STMicroelectronics

STTH30RQ06L2-TR Details

• Manufacturer Part Number:

  STTH30RQ06L2-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Factory Lead Time:

  25 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  7

• Application:

  HIGH VOLTAGE ULTRA FAST RECOVERY

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  2.95 V

• JESD-30 Code:

  R-PSSO-G7

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  215 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  175 °C

• Output Current-Max:

  30 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  40 µA

• Reverse Recovery Time-Max:

  0.055 µs

• Reverse Test Voltage:

  600 V

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  GULL WING

• Terminal Position:

  SINGLE
