SUTW60512 - Cosel

SUTW60512 Details

• Manufacturer Part Number:

  SUTW60512

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  PACKAGE-7

• ECCN Code:

  EAR99

• Manufacturer:

  Cosel USA Inc

• YTEOL:

  3

• Additional Feature:

  IT ALSO HAS -12V AND 24V OUTPUTS

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  UL; C-UL; EN

• Efficiency (Main Output):

  78%

• Input Voltage-Max:

  9 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-XSMA-T7

• Length:

  37.6 mm

• Line Regulation-Max:

  0.0072%

• Load Regulation-Max:

  5%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  7

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.25 A

• Output Voltage-Max:

  12.6 V

• Output Voltage-Min:

  11.4 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  260

• Protections:

  OVER CURRENT

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Seated Height-Max:

  26.9 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  15

• Total Power Output-Max:

  6 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.02 s

• Width:

  8.35 mm
