SWW246CD7 - Apem

SWW246CD7 Details

• Manufacturer Part Number:

  SWW246CD7

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  UK

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  APEM Inc

• YTEOL:

  7

• Actuator Length:

  0.295 inch

• Actuator Type:

  SHORT TYPE

• Body Breadth:

  11.35 mm

• Body Height:

  13 mm

• Body Length or Diameter:

  12.7 mm

• Bushing Diameter:

  0.244 inch

• Bushing Length:

  0.24 inch

• Contact (AC) Max Rating R Load:

  .02A@20VAC

• Contact Current(AC)-Max:

  0.02 A

• Contact Current(DC)-Max:

  0.02 A

• Contact (DC) Max Rating R Load:

  .02A@20VDC

• Contact Voltage(AC)-Max:

  20 V

• Contact Voltage(DC)-Max:

  20 V

• Electrical Life:

  100000 Cycle(s)

• Illumination:

  NON-ILLUMINATED

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• PCB Hole Count:

  8

• Sealing:

  EPOXY TERMINAL SEALED

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Terminal Finish:

  Gold (Au)

• Termination Type:

  SOLDER
