SX28AC/DP-G - Parallax

SX28AC/DP-G Details

• Manufacturer Part Number:

  SX28AC/DP-G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  GREEN, DIP-28

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Parallax Inc

• YTEOL:

  0

• Additional Feature:

  ALSO OPERATES 50 MHZ AT 3 V SUPPLY AND TEMP -40 TO 85

• Boundary Scan:

  NO

• Clock Frequency-Max:

  75 MHz

• Communication Protocol:

  I2C

• JESD-30 Code:

  R-PDIP-T28

• Length:

  35.306 mm

• Low Power Mode:

  YES

• Number of Terminals:

  28

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  5.334 mm

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  7.62 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, I2C BUS
