t20f400c3 - Efinix

t20f400c3 Details

• Manufacturer Part Number:

  T20F400C3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  FBGA-400

• HTS Code:

  8542.31.00.60

• Manufacturer:

  EFINIX

• JESD-30 Code:

  S-PBGA-B400

• Length:

  16 mm

• Moisture Sensitivity Level:

  3

• Number of Inputs:

  230

• Number of Logic Cells:

  19728

• Number of Outputs:

  230

• Number of Terminals:

  400

• Operating Temperature-Max:

  85 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFBGA

• Package Equivalence Code:

  BGA400,20X20,32

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Seated Height-Max:

  1.1 mm

• Supply Voltage-Max:

  1.25 V

• Supply Voltage-Min:

  1.15 V

• Supply Voltage-Nom:

  1.2 V

• Surface Mount:

  YES

• Technology:

  SMIC

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Width:

  16 mm
