T35F400I4 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and stackup for optimal signal integrity?
  EFINIX provides a reference PCB design guide that includes recommendations for layer stackup, signal routing, and decoupling. It's essential to follow these guidelines to ensure optimal signal integrity and minimize signal degradation.
• How do I implement a reliable and efficient power-on reset (POR) circuit?
  EFINIX recommends using an external POR circuit with a voltage supervisor IC, such as the TLV7031, to ensure a reliable and efficient power-on reset. The datasheet provides a reference design for the POR circuit.
• What are the best practices for thermal management and heat dissipation?
  EFINIX recommends using a heat sink with a thermal interface material (TIM) and ensuring good airflow around the device. The datasheet provides thermal resistance values and a thermal model to help with thermal management.
• How do I optimize the FPGA's power consumption and reduce power noise?
  EFINIX recommends using the device's built-in power management features, such as dynamic voltage and frequency scaling, and optimizing the design to minimize power consumption. Additionally, using a high-quality power supply and decoupling capacitors can help reduce power noise.
• What are the limitations and considerations for using the FPGA's internal oscillator?
  The internal oscillator is suitable for most applications, but it may not be suitable for high-frequency or high-precision applications. EFINIX recommends using an external oscillator or clock source for these types of applications.
