T90S5D12-24 - TE Connectivity

T90S5D12-24 Details

• Manufacturer Part Number:

  T90S5D12-24

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  24.1 mm

• Body Height:

  16.9 mm

• Body Length or Diameter:

  30.5 mm

• Coil Current(DC)-Max:

  0.036 A

• Coil Operate Voltage(DC):

  18 V

• Coil Power:

  900 mW

• Coil Release Voltage(DC):

  2.4 V

• Coil Resistance:

  660 Ω

• Coil Voltage(DC)-Max:

  24 V

• Coil Voltage-Nom:

  24 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  20 A

• Contact Current(DC)-Max:

  20 A

• Contact Resistance:

  75 mΩ

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  Silver Cadmium Oxide

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Terminals:

  6

• Operate Time:

  15 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  30.5mm x 24.1mm x 16.9mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Surface Mount:

  NO

• Terminal Length:

  0.0032994665989331978 inch

• Termination Type:

  SOLDER
