TA8233H - Toshiba

TA8233H Details

• Manufacturer Part Number:

  TA8233H

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZIP

• Package Description:

  HZIP-17

• Pin Count:

  17

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  50 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PZIP-T17

• JESD-609 Code:

  e0

• Number of Channels:

  2

• Number of Functions:

  2

• Number of Terminals:

  17

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Output Power-Nom:

  30 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP17,.08,.1,80

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  250 mA

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  9 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  OTHER

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2 mm

• Terminal Position:

  ZIG-ZAG
