TA8435H - Toshiba

TA8435H Details

• Manufacturer Part Number:

  TA8435H

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZIP

• Package Description:

  1.27 MM PITCH, PLASTIC, HZIP-25

• Pin Count:

  25

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Analog IC - Other Type:

  STEPPER MOTOR CONTROLLER

• JESD-30 Code:

  R-PZFM-T25

• JESD-609 Code:

  e0

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  2.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP25,.08

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max (Isup):

  18 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  BICMOS

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  ZIG-ZAG
