TAR5S15U - Toshiba

TAR5S15U Details

• Manufacturer Part Number:

  TAR5S15U

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Part Package Code:

  SSOP

• Pin Count:

  5

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  3

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.2 V

• Dropout Voltage1-Nom:

  1 V

• Input Voltage Absolute-Max:

  15 V

• Input Voltage-Max:

  15 V

• Input Voltage-Min:

  2.5 V

• JESD-30 Code:

  R-PDSO-F5

• Length:

  2.1 mm

• Line Regulation-Max:

  0.015%

• Load Regulation-Max:

  0.075%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Output Current1-Max:

  1 A

• Output Voltage1-Max:

  1.56 V

• Output Voltage1-Min:

  1.44 V

• Output Voltage1-Nom:

  1.5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VSOF

• Package Equivalence Code:

  FL6,.07,25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, VERY THIN PROFILE

• Qualification Status:

  Not Qualified

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  0.75 mm

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Terminal Form:

  FLAT

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Voltage Tolerance-Max:

  4%

• Width:

  1.7 mm
