TAR5SB33(TE85L,F) - Toshiba

TAR5SB33(TE85L,F) Details

• Manufacturer Part Number:

  TAR5SB33(TE85L,F)

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  SOT-23, 5 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  40 Weeks

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  3

• Adjustability:

  FIXED

• Dropout Voltage1-Max:

  0.2 V

• Input Voltage-Max:

  15 V

• Input Voltage-Min:

  3.5 V

• JESD-30 Code:

  R-PDSO-G5

• Length:

  2.9 mm

• Line Regulation-Max:

  0.015%

• Load Regulation-Max:

  0.075%

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage1-Max:

  3.39 V

• Output Voltage1-Min:

  3.21 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LSSOP

• Package Equivalence Code:

  TSOP5/6,.11,37

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  260

• Regulator Type:

  FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  1.4 mm

• Surface Mount:

  YES

• Technology:

  BIPOLAR

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.95 mm

• Terminal Position:

  DUAL

• Width:

  1.6 mm
