TB2904HQ - Toshiba

TB2904HQ Details

• Manufacturer Part Number:

  TB2904HQ

• Part Life Cycle Code:

  Active

• Part Package Code:

  ZIP

• Package Description:

  1 MM PITCH, PLASTIC, HZIP-25

• Pin Count:

  25

• Manufacturer:

  Toshiba America Electronic Components

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  26 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PZFM-T25

• Number of Channels:

  4

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Power-Nom:

  26 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  Not Qualified

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  9 V

• Surface Mount:

  NO

• Technology:

  BICMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
