TB67S158NG - Toshiba

Description: Capable of operating maximum of two 2-phase unipolar stepping motors by one chip. ・High voltage and current (as for specifications, please refer to the absolute maximum ratings and operation ranges). ・Low on resistance (Ron=0.5Ω (typ.)) of output step is realized by BiCD process

Download TB67S158NG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TB67S158NG - Toshiba PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - TB67H400ANG-1
click to zoom
3D Models
TB67S158NG - Toshiba  - 3D model - Dual-In-Line Packages - TB67H400ANG-1
click to zoom

TB67S158NG Details

  • Manufacturer Part Number:

    TB67S158NG

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SDIP-24

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • Analog IC - Other Type:

    STEPPER MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDIP-T24

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -20 °C

  • Output Current-Max:

    1.5 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SDIP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE, SHRINK PITCH

  • Supply Voltage-Max (Vsup):

    60 V

  • Supply Voltage-Min (Vsup):

    10 V

  • Supply Voltage-Nom (Vsup):

    24 V

  • Surface Mount:

    NO

  • Technology:

    BCDMOS

  • Temperature Grade:

    OTHER

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Position:

    DUAL

TB67S158NG Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the TB67S158NG is -40°C to 125°C, as specified in the datasheet. However, it's recommended to operate within -20°C to 85°C for optimal performance and reliability.
  • Thermal management is crucial for the TB67S158NG. Ensure good airflow around the device, use a heat sink if necessary, and follow the recommended PCB layout and thermal design guidelines provided in the datasheet and application notes.
  • The recommended input capacitor value is 10uF to 22uF, with a voltage rating of 25V or higher. A low-ESR ceramic capacitor, such as X5R or X7R, is recommended for optimal performance and stability.
  • Yes, the TB67S158NG is designed to operate in high-vibration environments. However, ensure that the device is properly mounted and secured to the PCB, and follow the recommended PCB layout and design guidelines to minimize the risk of mechanical stress and damage.
  • To troubleshoot issues with the TB67S158NG, follow a systematic approach: check the power supply, input voltage, and output voltage; verify the PCB layout and design; check for thermal issues; and consult the datasheet, application notes, and Toshiba's technical support resources.
