TC1-1+ Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance of the TC1-1+?
  Mini-Circuits recommends a 50-ohm microstrip line with a width of 0.035 inches (0.89 mm) and a substrate thickness of 0.031 inches (0.79 mm) for optimal performance. Additionally, it's recommended to keep the component away from any nearby metal objects or vias to minimize parasitic effects.
• Can I use the TC1-1+ in a non-50-ohm system?
  While the TC1-1+ is designed for 50-ohm systems, it can be used in non-50-ohm systems with some performance degradation. However, the impedance mismatch will affect the device's insertion loss, return loss, and isolation. It's recommended to consult with Mini-Circuits' application engineers for guidance on using the TC1-1+ in non-50-ohm systems.
• What is the maximum power handling of the TC1-1+?
  The TC1-1+ can handle up to 1 watt of continuous power, but it's recommended to derate the power handling to 0.5 watts or less for optimal reliability and performance. Exceeding the maximum power handling may result in device damage or degradation.
• Is the TC1-1+ suitable for high-reliability or space applications?
  The TC1-1+ is a commercial-grade component and may not meet the stringent requirements of high-reliability or space applications. Mini-Circuits offers specialized components for these applications, such as the TCR1-1+, which is designed for high-reliability and space applications.
• Can I use the TC1-1+ in a high-temperature environment?
  The TC1-1+ is rated for operation up to 85°C, but it's recommended to derate the operating temperature to 70°C or less for optimal reliability and performance. Exceeding the maximum operating temperature may result in device degradation or failure.
