TC275TP64F200WCAKXUMA1 - Infineon

TC275TP64F200WCAKXUMA1 Details

• Manufacturer Part Number:

  TC275TP64F200WCAKXUMA1

• Pbfree Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LQFP-176

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.31.00.25

• Factory Lead Time:

  33 Weeks

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  8.13

• Has ADC:

  YES

• Additional Feature:

  48 A/D INPUT LINES

• Bit Size:

  32

• Boundary Scan:

  YES

• CPU Family:

  TC27X

• Clock Frequency-Max:

  40 MHz

• DAC Channels:

  NO

• DMA Channels:

  YES

• Format:

  FLOATING POINT

• Integrated Cache:

  YES

• JESD-30 Code:

  S-PQFP-G176

• Length:

  24 mm

• Low Power Mode:

  YES

• Number of DMA Channels:

  64

• Number of I/O Lines:

  111

• Number of Terminals:

  176

• Number of Timers:

  2

• On Chip Data RAM Width:

  8

• On Chip Program ROM Width:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• PWM Channels:

  NO

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HLFQFP

• Package Equivalence Code:

  QFP176,1.0SQ,20

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, HEAT SINK/SLUG, LOW PROFILE, FINE PITCH

• RAM (bytes):

  327680

• ROM (words):

  4194304

• ROM Programmability:

  FLASH

• Seated Height-Max:

  1.6 mm

• Speed:

  200 MHz

• Supply Current-Max:

  550 mA

• Supply Voltage-Max:

  1.43 V

• Supply Voltage-Min:

  1.17 V

• Supply Voltage-Nom:

  1.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  24 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER
