TC75W58FU,LF - Toshiba

Description: Comparator General Purpose Open-Drain 8-SSOP , 7mV @ 5V , 25mA , 22µA , -40°C ~ 85°C

Download TC75W58FU,LF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TC75W58FU,LF - Toshiba PCB footprint - Other - Other - SSOP8-P-0.65_2025
click to zoom
3D Models
TC75W58FU,LF - Toshiba  - 3D model - Other - SSOP8-P-0.65_2025
click to zoom

TC75W58FU,LF Details

  • Manufacturer Part Number:

    TC75W58FU,LF

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SSOP-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    6

  • Amplifier Type:

    COMPARATOR

  • Input Offset Voltage-Max:

    7000 µV

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    2.9 mm

  • Number of Functions:

    2

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Type:

    OPEN-DRAIN

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LSSOP

  • Package Equivalence Code:

    TSSOP8,.16

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Response Time-Nom:

    190 ns

  • Seated Height-Max:

    1.3 mm

  • Supply Current-Max:

    0.044 mA

  • Supply Voltage Limit-Max:

    7 V

  • Supply Voltage-Nom (Vsup):

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    2.8 mm

TC75W58FU,LF Frequently Asked Questions (FAQs)

  • Toshiba recommends a PCB layout with a thermal pad connected to a large copper area on the bottom layer, and multiple vias to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended.
  • To ensure reliable operation in high-temperature environments, it's essential to follow proper thermal design and layout guidelines, and to consider derating the device's power consumption and operating frequency according to the temperature range.
  • Although the datasheet doesn't specify a maximum allowed voltage, it's generally recommended to limit the input voltage to 5.5V to prevent damage to the internal ESD protection diodes.
  • Yes, the TC75W58FU,LF is suitable for battery-powered applications due to its low power consumption and low standby current. However, it's essential to consider power management and sleep modes to minimize power consumption.
  • To troubleshoot I2C interface issues, check the clock frequency, signal integrity, and bus capacitance. Ensure that the I2C bus is properly terminated, and that the device is properly addressed and configured.
