The maximum cable length supported by the TCAN3413DDFR is approximately 40 meters, depending on the specific application and bus topology.
The TCAN3413DDFR is a CAN transceiver, and the protocol configuration is typically done at the microcontroller or system level. You need to configure the microcontroller's CAN controller to match the specific protocol requirements, such as bitrate, node ID, and message format.
The recommended termination resistor value for the TCAN3413DDFR is 120 ohms, as specified in the CAN bus standard. However, the actual value may vary depending on the specific application and bus topology.
The TCAN3413DDFR is rated for operation up to 125°C (junction temperature). However, it's essential to ensure that the device is properly heat-sinked and that the system is designed to operate within the specified temperature range.
To troubleshoot CAN bus communication issues, use a CAN bus analyzer or a logic analyzer to monitor the bus signals. Check for errors, such as bus off, error frames, or incorrect message formatting. Verify that the TCAN3413DDFR is properly configured, and the microcontroller's CAN controller is set up correctly.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TCAN3413DDFR Overview
Use the download button to access the TCAN3413DDFR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TCAN3,
or try a keyword search, such as Network Interfaces
