TCB502HQ - Toshiba

TCB502HQ Details

• Manufacturer Part Number:

  TCB502HQ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  HZIP-25

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  26 Weeks

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  6

• Consumer IC Type:

  AUDIO AMPLIFIER

• Harmonic Distortion:

  0.006%

• JESD-30 Code:

  R-PZIP-T25

• Length:

  28.8 mm

• Number of Channels:

  4

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Power-Nom:

  80 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HZIP

• Package Equivalence Code:

  ZIP25,.16,.16,40TB

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE, HEAT SINK/SLUG

• Seated Height-Max:

  19.37 mm

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  6 V

• Surface Mount:

  NO

• Technology:

  CDMOS

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1 mm

• Terminal Position:

  ZIG-ZAG

• Width:

  4.5 mm
