TCD1304DG(8Z,K) - Toshiba

TCD1304DG(8Z,K) Details

• Manufacturer Part Number:

  TCD1304DG(8Z,K)

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-22

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  5

• Array Type:

  LINEAR

• Body Height:

  3.22 mm

• Body Length or Diameter:

  41.6 mm

• Data Rate:

  1 Mbps

• Dynamic Range:

  49.5 dB

• Housing:

  CERAMIC, GLASS-SEALED

• Master Clock:

  2 MHz

• Mounting Feature:

  THROUGH HOLE MOUNT

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -25 °C

• Output Range:

  1.5-3.5V

• Output Type:

  ANALOG OUTPUT

• Package Shape/Style:

  RECTANGULAR

• Sensitivity (V/lx.s):

  160 V/lx.s

• Sensors/Transducers Type:

  IMAGE SENSOR,CCD

• Spectral Response (nm):

  400-1200

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  3 V

• Surface Mount:

  NO

• Termination Type:

  PIN
