TD62104FG - Toshiba

TD62104FG Details

• Manufacturer Part Number:

  TD62104FG

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SOIC

• Package Description:

  LEAD FREE, SOP-16

• Pin Count:

  16

• ECCN Code:

  EAR99

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Additional Feature:

  BUILT-IN BIAS RESISTOR RATIO IS 0.69

• Collector Current-Max (IC):

  0.5 A

• Collector-Emitter Voltage-Max:

  25 V

• Configuration:

  7 BANKS, DARLINGTON WITH BUILT-IN DIODE AND RESISTOR

• DC Current Gain-Min (hFE):

  1000

• JESD-30 Code:

  R-PDSO-G16

• Number of Elements:

  7

• Number of Terminals:

  16

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Polarity/Channel Type:

  NPN

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
