TDA1521 - NXP

TDA1521 Details

• Manufacturer Part Number:

  TDA1521

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SIP

• Package Description:

  POWER, PLASTIC, SOT-131, SIP-9

• Pin Count:

  9

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  30 dB

• Harmonic Distortion:

  0.5%

• JESD-30 Code:

  R-PSIP-T9

• Length:

  24 mm

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  9

• Output Power-Nom:

  12 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SIP

• Package Equivalence Code:

  SIP9,.1

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Supply Voltage-Max (Vsup):

  21 V

• Supply Voltage-Min (Vsup):

  7.5 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  SINGLE

• Width:

  4.4 mm
