TDA1554QU - NXP

TDA1554QU Details

• Manufacturer Part Number:

  TDA1554QU

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZIP

• Package Description:

  POWER, PLASTIC, SOT-243R, SIL-BENT-DIL, 17 PIN

• Pin Count:

  17

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  26 dB

• Harmonic Distortion:

  0.1%

• JESD-30 Code:

  R-PZIP-T17

• Length:

  24 mm

• Number of Channels:

  2

• Number of Functions:

  2

• Number of Terminals:

  17

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -50 °C

• Output Power-Nom:

  22 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP17,.1

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  245

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  17 mm

• Supply Current-Max:

  160 mA

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  6 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  ZIG-ZAG

• Time@Peak Reflow Temperature-Max (s):

  40

• Width:

  4.4 mm
