TDA2002V - STMicroelectronics

TDA2002V Details

• Manufacturer Part Number:

  TDA2002V

• Rohs Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZFM

• Package Description:

  PENTAWATT, ZFM-5

• Pin Count:

  5

• Reach Compliance Code:

  Not Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Additional Feature:

  HIGH OUTPUT CURRENT(3.5A)

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  40 dB

• Harmonic Distortion:

  0.2%

• JESD-30 Code:

  R-PZIP-T5

• JESD-609 Code:

  e0

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  5

• Output Power-Nom:

  10 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP5,.15,.2,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  8 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  ZIG-ZAG
