TDA2004A - STMicroelectronics

TDA2004A Details

• Manufacturer Part Number:

  TDA2004A

• Part Life Cycle Code:

  Active Unconfirmed

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  STMicroelectronics

• YTEOL:

  2

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  50 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PZIP-T11

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  11

• Output Power-Nom:

  12 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP11,.2,.17,67TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  120 mA

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  8 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.7 mm

• Terminal Position:

  ZIG-ZAG
