TDA2613 - NXP

TDA2613 Details

• Manufacturer Part Number:

  TDA2613

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SFM

• Package Description:

  POWER, PLASTIC, SOT-110B, SIP-9

• Pin Count:

  9

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Additional Feature:

  IT CAN ALSO OPERATE WITH 15V TO 42V SINGLE SUPPLY

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  30 dB

• Harmonic Distortion:

  0.5%

• JESD-30 Code:

  R-PSFM-T9

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -25 °C

• Output Power-Nom:

  6 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SFM

• Package Equivalence Code:

  SIP9,.1TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  35 mA

• Supply Voltage-Max (Vsup):

  42 V

• Supply Voltage-Min (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  OTHER

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE
