TDA7233 - STMicroelectronics

TDA7233 Details

• Manufacturer Part Number:

  TDA7233

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  MINI, DIP-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  39 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PDIP-T8

• JESD-609 Code:

  e3

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Output Power-Nom:

  1.9 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP8,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  5.08 mm

• Supply Current-Max:

  9 mA

• Supply Voltage-Max (Vsup):

  15 V

• Supply Voltage-Min (Vsup):

  1.8 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm
