TDA8754HL/14/C1,51 - NXP

TDA8754HL/14/C1,51 Details

• Manufacturer Part Number:

  TDA8754HL/14/C1,51

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFP

• Package Description:

  20 X 20 MM, 1.40 MM HEIGHT, PLASTIC, SOT-486-1, LQFP-144

• Pin Count:

  144

• HTS Code:

  8542.39.00.30

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  0

• Analog Input Voltage-Max:

  1 V

• Analog Input Voltage-Min:

  0.5 V

• Converter Type:

  ADC, PROPRIETARY METHOD

• JESD-30 Code:

  S-PQFP-G144

• JESD-609 Code:

  e4

• Length:

  20 mm

• Linearity Error-Max (EL):

  0.5078%

• Moisture Sensitivity Level:

  2

• Number of Analog In Channels:

  3

• Number of Bits:

  8

• Number of Functions:

  1

• Number of Terminals:

  144

• Operating Temperature-Max:

  70 °C

• Output Bit Code:

  BINARY

• Output Format:

  PARALLEL, 8 BITS

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, LOW PROFILE, FINE PITCH

• Qualification Status:

  Not Qualified

• Sample Rate:

  140 MHz

• Sample and Hold / Track and Hold:

  TRACK

• Seated Height-Max:

  1.6 mm

• Supply Current-Max:

  3.3 mA

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Silver (Ag)

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  20 mm
