TDE1898CDP - STMicroelectronics

TDE1898CDP Details

• Manufacturer Part Number:

  TDE1898CDP

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  MINI, DIP-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Built-in Protections:

  OVER CURRENT; THERMAL; UNDER VOLTAGE

• Driver Number of Bits:

  1

• Interface IC Type:

  BUFFER OR INVERTER BASED PERIPHERAL DRIVER

• JESD-30 Code:

  R-PDIP-T8

• JESD-609 Code:

  e3

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Output Current Flow Direction:

  SOURCE

• Output Current-Max:

  0.625 A

• Output Peak Current Limit-Nom:

  0.75 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP8,.35

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  5.08 mm

• Supply Voltage-Max:

  35 V

• Supply Voltage-Min:

  18 V

• Supply Voltage-Nom:

  24 V

• Supply Voltage1-Max:

  35 V

• Supply Voltage1-Min:

  9 V

• Surface Mount:

  NO

• Technology:

  BCDMOS

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  MATTE TIN

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Turn-off Time:

  20 µs

• Turn-on Time:

  100 µs

• Width:

  7.62 mm
