TFF1015HN/N1,135 - NXP

Description: IC MIXER 10.7-12.75GHZ 16DHVQFN

Download TFF1015HN/N1,135 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TFF1015HN/N1,135 - NXP PCB footprint - Other - Other - SOT763-1
click to zoom
3D Models
TFF1015HN/N1,135 - NXP  - 3D model - Other - SOT763-1
click to zoom

TFF1015HN/N1,135 Details

  • Manufacturer Part Number:

    TFF1015HN/N1,135

  • Source Url Status Check Date:

    2013-06-14 00:00:00

  • Brand Name:

    NXP Semiconductor

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    QFN

  • Package Description:

    MO-241, SOT-763-1, 16 PIN

  • Pin Count:

    16

  • Manufacturer Package Code:

    SOT763-1

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    0

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    LCC16,.1X.14,20

  • Power Supplies:

    5 V

  • Surface Mount:

    YES
