TGA2513-SM - Qorvo

Description: 2 - 20 GHz Wideband Low Noise Amplifier

Download TGA2513-SM Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TGA2513-SM - Qorvo PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - TGA2513-SM
click to zoom
3D Models
TGA2513-SM - Qorvo  - 3D model - Quad Flat No-Lead - TGA2513-SM
click to zoom

TGA2513-SM Details

  • Manufacturer Part Number:

    TGA2513-SM

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    4 X 4 MM, 0.90 MM HEIGHT, ROHS COMPLIANT, QFN-12

  • ECCN Code:

    EAR99

  • Manufacturer:

    Qorvo

  • YTEOL:

    0

  • Construction:

    COMPONENT

  • Gain:

    17 dB

  • Input Power-Max (CW):

    21 dBm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Functions:

    1

  • Number of Terminals:

    12

  • Operating Frequency-Max:

    20000 MHz

  • Operating Frequency-Min:

    2000 MHz

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    LCC12,.16SQ,25

  • Power Supplies:

    5 V

  • RF/Microwave Device Type:

    WIDE BAND LOW POWER

  • Surface Mount:

    YES

TGA2513-SM Frequently Asked Questions (FAQs)

  • A 4-layer PCB with a solid ground plane and thermal vias is recommended. Ensure good thermal conductivity by using a thermal pad and connecting it to a heat sink or a metal plate.
  • Use a resistive divider network to set the gate bias, and ensure the drain voltage is at least 2V above the knee voltage. Adjust the gate voltage to achieve the desired quiescent current.
  • Use a conjugate match at the input and output ports to achieve maximum power transfer. A series inductor and shunt capacitor can be used for input matching, while a series capacitor and shunt inductor can be used for output matching.
  • Use a resistive load at the output, and add a stabilizing capacitor (e.g., 10nF) between the drain and gate. Ensure the circuit is properly decoupled and use a low-ESR capacitor for power supply decoupling.
  • The maximum junction temperature is 150°C. Ensure the device is operated within the recommended temperature range to prevent thermal damage.
