TIG067SS-TL-2W footprint, schematic symbol and 3D model by onsemi

Symbol

PCB Footprints

3D Models

TIG067SS-TL-2W Details

The recommended PCB footprint for the TIG067SS-TL-2W is a 0603 package with a land pattern of 0.8mm x 0.8mm. It's essential to follow the recommended footprint to ensure proper thermal performance and to prevent overheating.
To ensure reliability in high-temperature applications, it's crucial to follow the recommended derating curves and thermal management guidelines provided in the datasheet. Additionally, consider using a heat sink or thermal interface material to improve heat dissipation.
The maximum allowable voltage for the TIG067SS-TL-2W is 67V. Exceeding this voltage may result in permanent damage to the device. It's essential to ensure that the voltage rating is not exceeded in the application.
To handle ESD protection for the TIG067SS-TL-2W, follow proper handling and storage procedures to prevent electrostatic discharge. Use ESD-protective packaging, wrist straps, and mats to prevent damage during handling and assembly.
The recommended storage condition for the TIG067SS-TL-2W is in a dry, cool place with a temperature range of -40°C to 125°C and humidity below 60%. Avoid exposing the device to direct sunlight, moisture, or extreme temperatures.

Manufacturer Collaborated

System Verified

Community Approved

Use the download button to access the TIG067SS-TL-2W schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like TIG06, or try a keyword search, such as IGBTs
