Texas Instruments recommends a compact layout with short traces, and placing the device close to the power source. Additionally, using a solid ground plane and separating analog and digital grounds can help reduce EMI and noise.
To ensure stability, make sure to follow the recommended compensation network values, and use a low-ESR output capacitor. Additionally, ensure the input voltage is within the recommended range, and the device is operated within its specified temperature range.
The TL1464IPT can deliver up to 3A of output current, but this is dependent on the input voltage, output voltage, and ambient temperature. Refer to the datasheet's thermal derating curves to determine the maximum output current for your specific application.
The TL1464IPT is rated for operation up to 125°C, but its performance and reliability may degrade at higher temperatures. Ensure you follow the recommended thermal design and derating guidelines to ensure reliable operation in high-temperature environments.
Start by verifying the input voltage, output voltage, and feedback connections. Check for any signs of overheating, and ensure the device is properly soldered and connected. Use an oscilloscope to monitor the output voltage and switching waveforms to identify any anomalies.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TL1464IPT Overview
Use the download button to access the TL1464IPT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TL146,
or try a keyword search, such as Switching Regulator or Controllers
