TL431D - IKSEMICON

TL431D Details

• Manufacturer Part Number:

  TL431D

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  SOP-8

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  IKSemicon Co Ltd

• Analog IC - Other Type:

  TWO TERMINAL VOLTAGE REFERENCE

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.9 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Output Voltage-Max:

  2.55 V

• Output Voltage-Min:

  2.44 V

• Output Voltage-Nom:

  2.495 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Seated Height-Max:

  1.75 mm

• Surface Mount:

  YES

• Temp Coef of Voltage-Max:

  61.94206595 ppm/°C

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Trim/Adjustable Output:

  YES

• Width:

  3.9 mm
